When the vertical labeling machine uses vertical labeling, Firmka summarizes a few points to note:
1. It is necessary to ensure the stability of the air pressure of the equipment. Because this method of labeling, when blowing the label, the blowing aid is required. Because the air consumption of the blowing mechanism is large, it must ensure that the air supply has sufficient supply. If the air supply is insufficient, not only It will guide the blowing force not enough, and it will also guide the suction power of the suction head, which will affect the stability of the labeling.
(How to check the gas supply situation: When the equipment is in continuous operation, look at the changes in the air pressure gauge on the equipment. If the pressure change on the air pressure gauge shows a large amount, it means that the air supply is insufficient. If the air supply is insufficient, the simplest Way is to add a gas storage buffer tank next to the equipment)
2. After ensuring stable gas supply
Check whether the suction hole of the suction head has strong suction power. If the suction power is not enough, the suction head is easy to suck the label. Even if it is sometimes sucked, it is easy to drop the label during the operation of the suction head.
(How to determine the suction power of the suction head: let the suction head be simply inhaled, take a piece of paper and place it on the suction head, pull a piece of paper by hand, see if the pulling force is strong, feel the suction head Whether the suction force can completely absorb the label, if the label can be pulled easily, it means that the suction is not enough. If the suction is not enough, check whether the suction hole is blocked, if the suction hole is blocked, guide it through can)
3. If there is no problem with the above two points
Check to see if the blower is in the correct direction
(It is necessary to blow the air blowing hole at an oblique angle to the direction of the printer outlet and the suction head)
4. Through the standard suction test, check whether the label is completely detached from the printer after the label is sucked and before running forward. Make sure that the entire label has entered the label, especially the small label , Not to leave a little tail.
(If the label has completely detached from the printer and does not enter the suction head flat, check whether the suction head is flat and whether the label receives resistance on the suction head;
If this is the case, the surface of the suction head needs to be treated. If the surface of the suction head is flat, check whether the direction angle of the blow hole on the blow bar is appropriate.
If the label is not completely separated from the printer and the label has a little tail on the printer, the printer and printer software must be set up so that the printer is finished and the label paper is completely removed from the printer outlet.
