The boiler body is stamped and welded with high-quality stainless steel plates. The emulsification process of the emulsification tank is carried out under fully sealed conditions, which effectively avoids dust and microbial pollution. In the vacuum state, the materials in the water tank and the oil pan are directly sucked into the emulsification tank through the conveying pipeline. The discharging method is the tilting type of the emulsification boiler body, the boiler interlayer is connected by the electric heating tube, and the material is heated by the internal heat transfer medium. The heating temperature can be arbitrarily set and automatically controlled. The material can be cooled by connecting cooling water in the interlayer. The operation is simple and convenient, and the insulating layer is arranged outside the interlayer. Homogeneous mixing and paddle mixing can be used alone or together. The particle size, emulsification, mixing, mixing and dispersion of materials can be completed in a short time. The materials in the tank are emulsified by the high-speed internal circulation shear mixing of the homogenizer, the second mixing in the reverse direction, the frame-type wall scraping mixing in the clockwise direction, and the slurry mixing in the counterclockwise direction. The scraper mixer has a centrifugal effect during the operation process, so that the PTFE scraper is close to the furnace wall, which effectively handles the problem of material sticking to the furnace wall without leaving dead corners. The ideal frequency conversion speed control equipment can make the furnace wall speed arbitrarily stepless.
The equipment is equipped with a common integrated mirror device on the pot cover, equipped with a closed lamp, so that the operator can observe the emulsification status of the material at any time. The whole structure is a three-layer structure. The heating and cooling of the equipment are completed in the same jacket. The outer layer of the jacket has an aluminum silicate insulation layer, which can prevent the operator from being burned and ensure the safety of production. Secondly, the boiler body is equipped with cooling water inlet and outlet. The lid is equipped with various quick equipment interfaces, which users can choose according to their needs (sterile air respirator, suction port, vacuum pump interface, cleaning ball, CPI interface, trace element addition port, integrated mirror window, vacuum gauge). Use high-quality stainless steel to touch the material (medical 316L material, mirror polished inner surface, sanitary and clean vacuum mixing equipment, manufactured according to GMP specifications)
