Common issues and methods for self-adhesive labeler

16/08/2019

Firstly, the labeling position is unstable
1. The pressure belt device may not be pressed, causing the belt to be loose and the detection sensor to be inaccurate;
2. The traction mechanism of the labeling machine may be slippery or not pressed, resulting in the failure to take the liner paper smoothly, resulting in different lengths of the bidding;
3. The labeling speed and the conveying speed do not match;
4. The slope of the pressure-sensitive brush at the stripping plate is not suitable. When the label is sent out, the label should be close to the brush, so that the angle of the label is consistent.

Second, the direction of the label is gradually wrong during the labeling process.
1. The pressure belt device is too tight, causing the deviation of the belt and the pressure of the belt to be reduced;
2. The label correction is not performed before the automatic labeling machine is automatically operated, and the correction can be performed again;
3. The stripping plate is skewed and the label is deflected. Just adjust the stripping plate.

Thirdly, the quality of labeling machine labeling is not good, there are bubbles or wrinkles on the bottle
1. It is possible that the overlaying wheel and the surface to be veneered are not parallel, and the overlaying wheel can be adjusted;
2, the bidding speed and conveying speed and the coating speed are not matched, mostly the bidding speed is too fast, and the bidding speed or conveying speed is re-adjusted;
3. The label strength is not enough, and it is easy to wrinkle during the bidding or labeling process.
